Product Description
Material: Brass / Brass with nickel Plated ( Furnished with insulating Liner)
Protection Degree: IP67
Thread Type: Metric, but PG & G Thread can also be produced
Function:
1. Can be used in flexible metallic conduit or liquid tight conduit in Power Plant, Power transmission system, communication system, building factory, railway, train, transportation system project, air conditioner, various machines, automates controlling plant. And it protects the electrical wire or cable outside the construction and plant.
2. Use to positively bond the conduit to a box or enclosure.
90 Degree Elbow Metal Conduit Fittings – Metric Thread
| Product Code | Thread O.D | Cable range (mm) | Length (mm) | Thread length GL(mm) | Spanner Size (mm) |
| JX-M12-9D | 12 | 3-6.5 | 45 | 9 | 20/21 |
| JX-M16-6.5-9D | 16 | 3-6.5 | 45 | 9 | 20/21 |
| JX-M16-8-9D | 16 | 4-8 | 45 | 9 | 20/21 |
| JX-M16-10-9D | 16 | 5-10 | 57 | 10 | 20/25 |
| JX-M18-9D | 18 | 5-10 | 57 | 10 | 20/25 |
| JX-M20-10-9D | 20 | 5-10 | 57 | 10 | 24/25 |
| JX-M20-12-9D | 20 | 6-12 | 57 | 10 | 24/30 |
| JX-M20-14-9D | 20 | 8-14 | 58 | 15 | 24/30 |
| JX-M22-9D | 22 | 8-14 | 58 | 15 | 24/30 |
| JX-M24-12-9D | 24 | 6-12 | 58 | 15 | 24/30 |
| JX-M24-14-9D | 24 | 8-14 | 58 | 15 | 24/30 |
| JX-M25-14-9D | 25 | 8-14 | 58 | 15 | 28/34 |
| JX-M25-16-9D | 25 | 10-16 | 75 | 15 | 30/34 |
| JX-M25-18-9D | 25 | 13-18 | 75 | 15 | 28/34 |
| JX-M27-16-9D | 27 | 10-16 | 75 | 15 | 30/34 |
| JX-M27-18-9D | 27 | 13-18 | 75 | 15 | 28/34 |
| JX-M30-16-9D | 30 | 10-16 | 75 | 15 | 30/34 |
| JX-M30-18-9D | 30 | 13-18 | 75 | 15 | 30/34 |
| JX-M32-18-9D | 32 | 13-18 | 75 | 15 | 30/34 |
| JX-M32-22-9D | 32 | 15-22 | 75 | 15 | 30/43 |
| JX-M32-25-9D | 32 | 18-25 | 90 | 15 | 40/43 |
| JX-M33-9D | 33 | 18-25 | 90 | 15 | 40/43 |
| JX-M36-22-9D | 36 | 15-22 | 90 | 15 | 36/43 |
| JX-M36-25-9D | 36 | 18-25 | 90 | 15 | 40/43 |
| JX-M40-25-9D | 40 | 18-25 | 90 | 15 | 40/43 |
| JX-M40-30-9D | 40 | 22-30 | 105 | 15 | 50/55 |
| JX-M40-32-9D | 40 | 22-32 | 115 | 15 | 50/55 |
| JX-M42-9D | 42 | 22-32 | 115 | 15 | 50/55 |
| JX-M48-9D | 48 | 22-32 | 115 | 15 | 50/55 |
| JX-M50-9D | 50 | 30-38 | 115 | 15 | 55/60 |
| JX-M56-9D | 56 | 30-38 | 115 | 15 | 55/60 |
| JX-M60-9D | 60 | 37-44 | 125 | 18 | 65/70 |
| JX-M63-9D | 63 | 37-44 | 125 | 18 | 75/75 |
| JX-M64-9D | 64 | 37-44 | 125 | 18 | 65/70 |
